Posts Tagged ‘USB Restricted Mode’

iOS 12 Enhances USB Restricted Mode

Thursday, September 20th, 2018

The release of iOS 11.4.1 back in July 2018 introduced USB Restricted Mode, a feature designed to defer passcode cracking tools such as those developed by Cellerbrite and Grayshift. As a reminder, iOS 11.4.1 automatically switches off data connectivity of the Lightning port after one hour since the device was last unlocked, or one hour since the device has been disconnected from a USB accessory or computer. In addition, users could manually disable the USB port by following the S.O.S. mode routine.

iOS 12 takes USB restrictions one step further. According to the new iOS Security guide published by Apple after the release of iOS 12, USB connections are disabled immediately after the device locks if more than three days have passed since the last USB connection, or if the device is in a state when it requires a passcode.

“In addition, on iOS 12 if it’s been more than three days since a USB connection has been established, the device will disallow new USB connections immediately after it locks. This is to increase protection for users that don’t often make use of such connections. USB connections are also disabled whenever the device is in a state where it requires a passcode to re-enable biometric authentication.”

Source: Apple iOS Security, September 2018 (more…)

iOS 12 Beta 5: One Step Forward, Two Steps Back

Tuesday, July 31st, 2018

The release of iOS 11.4.1 marked the introduction of USB restricted mode, a then-new protection scheme disabling USB data pins after one hour. The USB restricted mode was not invincible; in fact, one could circumvent protection by connecting the device to a $39 accessory. While a great improvement on itself, the new mode did not provide sufficient protection. We wished Apple maintained a list of “trusted” or previously connected accessories on the device, allowing only such devices to reset the timer. In this new iOS 12 beta, Apple makes attempts to further “improve” USB restricted mode, yet the quotes about “improving” the system are there on purpose.

We recently covered the whole story starting from iOS 11.3 and up to the then-current iOS 12 beta, but it looks the story is far from the end. I think Apple monitors media coverage including our blog, and takes a note on some of the readers’ comments in an attempt to find the right balance between security and convenience. We even suggested how they could possibly improve the new mode’s implementation, and… iOS 12 Beta 5 (just released) brings another surprise.

(more…)

USB Restricted Mode Inside Out

Thursday, July 12th, 2018

It’s been a lot of hype around the new Apple security measure (USB restricted mode) introduced in iOS 11.4.1. Today we’ll talk about how we tested the new mode, what are the implications, and what we like and dislike about it. If you are new to the topic, consider reading our blog articles first (in chronological order):

To make a long story short: apparently, Apple was unable to identify and patch vulnerabilities allowing to break passcodes. Instead, they got this idea to block USB data connection after a period of time, so no data transfer can even occur after a certain “inactivity” period (keep reading about the definition of “inactivity”). It is somehow similar to how Touch ID/Face ID expire from time to time, so you can only use the passcode if you did not unlock the device for a period of time. Same for USB now.

(more…)

This $39 Device Can Defeat iOS USB Restricted Mode

Monday, July 9th, 2018

The most spoken thing about iOS 11.4.1 is undoubtedly USB Restricted Mode. This highly controversial feature is apparently built in response to threats created by passcode cracking solutions such as those made by Cellerbrite and Grayshift. On unmanaged devices, the new default behavior is to disable data connectivity of the Lightning connector after one hour since the device was last unlocked, or one hour since the device has been disconnected from a trusted USB accessory. In addition, users can quickly disable the USB port manually by following the S.O.S. mode routine.

Once USB Restricted Mode is engaged on a device, no data communications occur over the Lightning port. A connected computer or accessory will not detect a “smart” device. If anything, an iPhone in USB Restricted Mode acts as a dumb battery pack: in can be charged, but cannot be identified as a smart device. This effectively blocks forensic tools from being able to crack passcodes if the iPhone spent more than one hour locked. Since law enforcement needs time (more than one hour) to transport the seized device to a lab, and then more time to obtain an extraction warrant, USB Restricted Mode seems well designed to block this scenario. Or is it?

We performed several tests, and can now confirm that USB Restricted Mode is maintained through reboots, and persists software restores via Recovery mode. In other words, we have found no obvious way to break USB Restricted Mode once it is already engaged. However, we discovered a workaround, which happens to work exactly as we suggested back in May (this article; scroll down to the “Mitigation” chapter).

(more…)

iOS 11.4.1 Beta: USB Restricted Mode Has Arrived

Saturday, June 2nd, 2018

As we wrote back in May, Apple is toying with the idea of restricting USB access to iOS devices that have not been unlocked for a certain period of time. At the time of publication, our article received a lot of controversial reports. When this mode did not make it into the final build of iOS 11.4, we enjoyed a flow of sarcastic comments from journalists and the makers of passcode cracking toolkits. Well, there we have it: Apple is back on track with iOS 11.4.1 beta including the new, improved and user-configurable USB Restricted Mode.

What’s It All About?

The USB Restricted Mode first made its appearance in iOS 11.3 beta. The idea behind this mode is well covered in our previous article iOS 11.4 to Disable USB Port After 7 Days: What It Means for Mobile Forensics. At the time of 11.3 beta, the feature had the following description:

“To improve security, for a locked iOS device to communicate with USB accessories you must connect an accessory via lightning connector to the device while unlocked – or enter your device passcode while connected – at least once a week.”

The idea behind USB Restricted Mode was pretty ingenious. The feature appeared to be directly targeting passcode cracking solutions such as those made by Cellerbrite and GrayShift. The device running iOS 11.3 beta would disable the USB data connection over the Lightning port one week after the device has been last unlocked. The feature was not user-configurable, but it could be disabled via corporate policies and device management solutions.

Apparently, the feature did not make it into the final release iOS 11.3. While we had reasons to believe it would be included with iOS 11.4, Apple skipped it in iOS 11.4, replacing it instead with a toned-down version that would require unlocking the iOS device after 24 hours in order for it to communicate with a USB accessory. While this toned-down feature would complicate the work of forensic experts by effectively disabling logical acquisition with lockdown records, it had zero effect on passcode cracking solutions such as those offered by Cellebrite and GrayShift.

The “proper” USB Restricted Mode, the one that would completely shut down all data communications between the iOS device and the computer, was still missing in iOS 11.4. Only to reappear – in a much refined form – in iOS 11.4.1 beta. (more…)
